Tri-Clamp 90° Elbow
A right-angle tube fitting with clamp ends for perpendicular pipe runs, with five tube and clamp-size combinations.
Material | SS304 |
|---|---|
Connection | Tri-Clamp |
Bend angle | 90° |
Select an option to include it in your enquiry.
Product overview
Product structure
90-degree clamp elbow for connecting two pipes or tubes at an angle.
Fitting connects to tubing on both ends.
The elbow’s connection is beveled to allow for a smooth bore and better fluid flow.
Material and construction
This tri clamp elbow fitting is made of SS304.
Application
It is suitable for use in food, beverage, and dairy applications.
Prepare your enquiry
End connections · Size range · Material · Seal or gasket · Service fluid · Operating conditions · Quantity
Technical specifications
Connections & dimensions
- Connection
- Tri-Clamp
Materials & seals
- Material Options
- 304
Construction & finish
- Angle
- 90 degrees
Dimension data and symbol key
Dimensional reference
Pipe OD | Ferrule OD | Fits Tri-clamp |
|---|---|---|
25mm/38mm | 51MM | 1.5" |
51mm | 64MM | 2" |
76mm | 91MM | 3" |
101.5mm | 119MM | 4" |
