Pneumatic Three-Way Tri-Clamp Diaphragm Valve
The pneumatic three-way clamp-end diaphragm valve has a top actuator and three-port body, with clamp pipe connections at the ports.
Material | SS316L |
|---|---|
Connection | Clamped |
Actuation | Pneumatic |
Specification | DN15-DN80 |
Shape | U Type |
Product overview
Product structure
A Tri-Clamp joint connects mating ferrules with a separate clamp and gasket. Three ports form the valve flow arrangement. A pneumatic actuator forms the operating assembly.
Pneumatic Three-Way Tri-Clamp Diaphragm Valve. A diaphragm valve uses a flexible diaphragm to separate the operating mechanism from the flow passage. Select the body arrangement and diaphragm for the intended line.
Selection checks
- Body and port arrangement
- Diaphragm material and medium compatibility
- End connections and actuation
Prepare your enquiry
End connections · Size range · Material · Seal or gasket · Service fluid · Operating conditions · Quantity
Technical specifications
Materials & seals
- Material Options
- AISI316L
- Material Options
- SS316L
Product series
- Media / applications
- Water (Product series)
- Seal material
- EPDM+PTFE (Product series)
- Interface standard options
- 3A/DIN/SMS/ISO/IDF (Product series)
Need a different size, connection or document?
Discuss your requirements
