Manual T-Type Three-Way Tri-Clamp Diaphragm Valve
The manual T-type three-way diaphragm valve combines a top handwheel with three clamp ports in a branched body layout.
Model | JOV-DHMU301-22 |
|---|---|
Material | SS316L |
Connection | Clamped |
Specification | DN15-DN80 |
Shape | T Type |
Product overview
Product structure
A Tri-Clamp joint connects mating ferrules with a separate clamp and gasket. Three ports form the valve flow arrangement.
Manual T-Type Three-Way Tri-Clamp Diaphragm Valve. A diaphragm valve uses a flexible diaphragm to separate the operating mechanism from the flow passage. Select the body arrangement and diaphragm for the intended line.
Selection checks
- Body and port arrangement
- Diaphragm material and medium compatibility
- End connections and actuation
Prepare your enquiry
End connections · Size range · Material · Seal or gasket · Service fluid · Operating conditions · Quantity
Technical specifications
Materials & seals
- Material Options
- AISI304, AISI316L
- Material Options
- SS316L
Product series
- Seal material
- EPDM+PTFE (Product series)
- Interface standard options
- 3A/DIN/SMS/ISO/IDF (Product series)
