Pneumatic Three-Piece Male-Thread Ball Valve

Control and feedback

The series offers stainless steel and aluminum pneumatic actuators, with position sensors or solenoid valves as accessories. Control accessories need to match the actuator arrangement.

Sealing

The three-piece ball valve has a direct actuator mounting pad. The series offers a cavity-filled seat that reduces open space in the body cavity and facilitates cleaning of the valve passage.

The seat sealing material is PTFE.

Construction and assembly

The page describes a series arrangement with replaceable end connections. The end configuration needs to match the selected model and dimensions.

Applications

The page lists dairy, food, beverage, pharmaceutical, cosmetic and chemical equipment piping as applications.

Assembly & Selection Notes

Fasteners assemble the central body and ends, and the actuator drives the ball through the stem. Compare mating threads, air connections and body length, with access to the actuator, threaded joints and body fasteners.
