Square-Body Valve Manifold
The square-body valve manifold has manual valves on the branches of a rectangular main header, forming a distribution assembly with branch operating positions.
Material | SS304, SS316L |
|---|---|
Connection | Male Thread |
Product overview
Product structure
Branch connections and valves are arranged on the distribution body. The manifold body, branch piping and valves are distinct parts of the assembly; their interfaces should be read separately.
A valve manifold with a square-body form, combining the manifold body and valve interfaces in one assembly. Confirm the port layout, mating connections and valve arrangement against a dimensioned project drawing.
Selection checks
- Port count, positions and connection dimensions
- Valve interfaces and control arrangement
- Mounting envelope, supplied material and service conditions
Prepare your enquiry
End connections · Size range · Material · Seal or gasket · Service fluid · Operating conditions · Quantity
